The Merida eOne-Sixty 675 Electric Enduro Bike in Silk Fog Green/White is designed for those who crave adventure on challenging terrains. Equipped with a powerful Shimano mid-drive motor, it delivers a seamless and efficient ride, while the 712Wh battery ensures you can explore further without worrying about running out of power. The bike's robust alloy frame and advanced suspension system provide stability and comfort, making it perfect for tackling rough trails. With hydraulic disc brakes, you can enjoy precise stopping power, enhancing your safety on descents. This e-bike is a perfect blend of performance and style, ready to elevate your off-road experiences.



Frame
• Merida eONE-SIXTY LITE IV
• MAT Aluminum Frame
• 160mm Travel
• 29" Front / 27.5" Rear
• 148x12 Axle Standard
• Internal 750Wh Battery Integration
• Max Tire Clearance: 29x2.6"

Suspension
• Fork: Marzocchi Z1 eMTB
• Air Spring
• 170mm Travel
• Tapered Steerer
• 44mm Offset
• Max Tire Size: 29x2.6"
• Rear Shock: Marzocchi Bomber Air
• Platform Adjust

Drivetrain
• Shifter: SRAM Eagle 70 Transmission Shifter
• Rear Derailleur: SRAM Eagle 70 Transmission
• Cassette: SRAM XS-1270 T-Type, 10–52t, 12spd
• Chain: SRAM Eagle 70 Flattop
• Crankset: SRAM XX Eagle Transmission E-MTB for Shimano Steps
• Shimano FC-EM600
• 36T Chainring
• 165mm Crank Length
• Pedals: VP VPE-527

Brakes
• Front Brake: SRAM DB6 Stealth, 4-Piston
• Rear Brake: SRAM DB6 Stealth, 4-Piston
• Front Rotor: SRAM CenterLine, 220mm
• Rear Rotor: SRAM CenterLine, 200mm

Cockpit
• Handlebar: Merida Expert eTR, 780mm
• Stem: Merida Expert eTR II
• MAT Aluminum
• 35mm Clamp
• 40mm Length
• Supernova Mount Compatible
• Grips: Merida Expert EC
• Headset: Acros ICR Merida External Neck w/ Blocklock

Seating
• Saddle: Merida Comp SL
• V-Mount
• Includes Integrated Merida Mini Tool
• Seatpost: Merida Expert TR II, 34.9mm
• Dropper Travel:
• XS: 125mm
• S: 150mm
• M: 170mm
• L: 200mm
• XL: 230mm
• Seat Clamp: Merida Expert

Wheels
• Rims: Reynolds 309 Enduro Comp
• 30mm Internal Width
• Tubeless Ready
• Tubeless Tape Installed
• Front: 29"
• Rear: 27.5"
• Front Hub: Novatec SL-Elite D041SB-B15, 110x15, 32h, 6-Bolt
• Rear Hub: Novatec SL-Team D462SB-S3S-B12-11S, 148x12, 32h, 6-Bolt
• Spokes: Black Stainless w/ Black Nipples
• Front Tire: Maxxis Assegai 29x2.5"
• EXO+
• 3C MaxxGrip
• Tubeless Ready Folding
• Rear Tire: Maxxis Minion DHR II 27.5x2.4"
• DoubleDown
• 3C MaxxTerra
• Tubeless Ready Folding

E-Bike System
• Motor: Shimano STePS EP801
• Mid-Drive System
• 85Nm Torque
• 250W Power
• 25km/h Assist Limit
• Battery: Shimano BT-EN817, 712Wh
• Display: Shimano SC-EM800

Accessories
• Fender: EOF-204
• Merida Multitool w/ Saddlebox
• Front Light: Lezyne Hekto StVZO E350+
• Rear Light: Lezyne Femto USB-C Rear StVZO
• Rear Axle: Merida Expert TR
• Includes Removable Lever
• Integrated 6mm / 4mm Allen Keys
