FRAME     New Frame, Updated Geometry and Hydroformed tubing, Tapered headtube, T6 - 6061 Aluminium, semi-internal cable routing, dropper post compatible, replaceable derailleur hanger,
FRAME CONT.     148mm x 12mm through axle dropouts, 18mm direct-mount 2-bolt kickstand, water bottle bosses, ISCG Tabs, 29" x 2.5" tyre clearance, rack and fender mounts
FORK     SR Suntour X1 Boost Air LOR DS, 120mm Travel, 32mm Black Stanchions, LOR Damper
HEADSET     Semi-Integrated Threadless Headset
HANDLEBAR     Alloy Handlebar, Dia: 31,8mm, 680mm, 9° Backsweep, 12mm Rise, Sanblasted Black
STEM     Alloy Stem, 31.8mm, ±6° Rise
GRIP     TPR Single Density Grips, Black
WHEELSET     SURFACE Custom Wheelset
RIM-FRONT     29" Asymmetrical Alloy Rim, Tubeless Ready
RIM-REAR     29" Asymmetrical Alloy Rim, Tubeless Ready
HUB-FRONT     Shimano HB-TC500-15-B Front Hub, Centre Lock, 32H, 15mm Thru-Axle, OLD: 110mm
HUB-REAR     Shimano FH-TC500-HM-B Freehub, Centre Lock, 8-11 Speed, 12mm Thru-Axle, 32H, OLD: 148mm
TIRE-FRONT     Maxxis Rekon 29x2,4"
TIRE-REAR     Maxxis Rekon 29x2,4"
SPOKE     14G Stainess Black Spokes
CHAIN     Shimano CN-LG500 LG Chain, 118 Links, 9/10/11 Speed
CRANKSET     Shimano FC-U4000-1 CUES, 32T
CHAINRING     NIL
PEDAL     One Piece Alloy Pedal, Black
BRAKE-FRONT     Shimano BL-MT200(L) with BR-MT200(F) Altus Disc Brake Assembled Set, 800mm Hose
BRAKE-REAR     Shimano MT200 Rear Hydraulic Disc Brake, 180PM, Resin Pads, 1700mm Hose
ROTOR-FRONT     Shimano SM-RT54 Deore Rotor, 180mm, with External Serration Lock Ring
ROTOR-REAR     Shimano SM-RT54 Deore Rotor, 180mm, with External Serration Lock Ring
DERAILLEUR-FRONT     NIL
DERAILLEUR-REAR     Shimano RD-U6000 CUES Rear Derailleur 10/11 Speed
SHIFTER-LEFT     NIL
SHIFTER-RIGHT     Shimano SL-U6000-10R CUES 10-Speed Right Shift Lever, Rapidfire Plus w/o Optical Gear
CASSETTE     Shimano CS-LG300-10 CUES 10-Speed Cassette, 11-48T
SADDLE     Nylon Base Saddle, Black
SEAT POST     Alloy, 30.9mm, Black Seat Post
SEAT POST CLAMP     Alloy 34,9mm QR Clamp
